Urinal Sensor – UT-119B
Recessed electronic infrared flushing control for urinal with a vandal proof complete stainless steel plate in satin finish.
- Product Features
Solid brass valve with built-in flow control valve and strainer fitted within the outer stainless steel box.
- Product Specifications
Model No. UT-119B UT-119C UT-119B+C Battery Operated Electrically Operated Electrical Operated with Battery Backup External Material Screwless s/s plate Screwless s/s plate Screwless s/s plate Dimensions 125 X 125 mm 125 X 125 mm 125 X 125 mm Power 4 “AA” Alkaline Batteries AC220V/50Hz 4 “AA” Alkaline Batteries + AC220V/50Hz Battery life 2 year’s with 100 operations /day (Optional) Battery standby 2 year’s with 100 operations /day Water pressure 0.4-8 bar 0.4-8 bar 0.4-8 bar Detection range Automatic Automatic Automatic Flushing time 6 s 6 s 6 s Plumbing Connections G 1/2” G 1/2” G 1/2” Ambient temperature 1~55°C 1~55°C 1~55°C Power consumption in satic = 0.5 mW (DC), =3W(AC) = 0.5 mW (DC), =3W(AC) = 0.5 mW (DC), =3W(AC) - Documents
